NTA 370 G: FULLY-AUTO DOUBLE-COLUMN COLD SAW WITH PROGRAMMABLE AUTO-HEAD ROTATION


NTS 370 3.jpg


Pricing starts at $49,200




The Quantum NTA 370 G Vertical Double-Column, Fully-Automatic Cold Saw is the end-all-solution for most of your metal cutting needs! The NTA 370 G has a fully-programmable, moveable head that can automatically miter up to 45 degrees right and can automatically miter up to 45 degrees left via the mounted CNC Touchscreen Control; which allows you to have complete control over the cutting lengths, mitering points, and much more! The NTA 370 G sports a vice that is complete with an anti-burr device, and a high-quality, Italian motor pump for smooth blade lubrication. The quality, build, and innovation of this unit make it unique to the market, to help further advance any shop with their metal cutting needs, allowing you to get miles ahead of the competition!


Operation:
1. Material feeding.
2. Fixed vice lock.
3. Rotation of the blade and delivery of the coolant, head down-feed until the finishing of the cut, feeding carriage return until the fixed measure.
4. Head return, blade and coolant delivery stopping.
5. Vice opening.
6. Cycle repetition.

NTA 370 G CUTTING CAPACITIES AND SPECIFICATIONS:

  • Round Tube Cutting at 90° (Straight Cut) - 4.50"
  • Round Tube Cutting at 45° - 4.50"
  • Square Tube Cutting at 90° (Straight Cut) - 4.25"
  • Square Tube Cutting at 45° - 4.25"
  • Rectangular Tube Cutting at 90° (Straight Cut) - 3.75" Height x 4.50" Width
  • Rectangular Tube Cutting at 45° - 3.75" Height x 4.50" Width
  • Maximum vice opening: 4.9" (125mm)

Features:

  • Automatic CNC hydraulic circular cold saw performing cuts from 0° to 45° to the right and left produced according to the current safety standards.
  • Additional Vice
  • Variable Speed Inverter
  • Stroke feeder material 39”
  • Overall dimensions: 11.5’ x 4’ x 6.3’
  • Motor pump
  • Vice pressure regulator
  • Tempered and ground vertical slider
  • Tempered and ground vice jaws
  • Head lowering adjustment
  • Service tools
  • Instruction manual and exploded view of spare parts.
  • The NTA 370 G is to be equipped with a 370mm blade.
    (Our 370mm HSS Quantum Circular Cold Saw Blades are only $150 each!!)

The videos below display the NTA 370 G's ability to automatically miter the head within a program.


REQUEST QUOTE FOR THE NtA 370 G:
fully-AUTOMATIC double-column COLD SAW with programmable mitering head

Name *
Name
Phone *
Phone
(We ask this, only to ensure that this unit will be best suited for your applications, since we offer such a wide range of saws to choose from.)

Most recent testimonial on the NTA 370 G



"Cutting Angles on the
NTA370G works fantastic,
extremely fast..."

- Robert Zusto (President of Zusto Architectural Metal & Glass)
